| power |
6000 W |
| voltage |
230 V |
| mounting diameter |
47.5 mm |
| heating circuits |
3 |
| length |
400 mm |
| width |
24 mm |
| height |
42 mm |
| number of thermostat sleeves |
1 |
| diameter thermostat sleeves |
9 mm |
| length thermostat sleeves |
245 mm |
| position thermostat sleeve |
not clinging |
| tube diameter |
6.3 mm |
| hole distance |
62 mm |
| hole diameter |
8 mm |
| connection |
M4 |
| mounting |
3 hole flange |
| application |
immersion heater |
LUXIA - Dishwasher hood type - K1300, POLY 1500
MACH - Dishwasher - MGL500, MS400, MS400B, MS400T, MS450, MS450E, MS500, MS500B, MS500PPB, MS500T, MS700, MS700E, MS800B, MS800E, MS800T, MS9800, MS9801, MS9803
MACH - Dishwasher hood type - MS1100, MS1100E, MS1100P, MS1100T, MS1300, MS1300E, MS1300P, MS1300T, MS900, MS900E, MS900T, MS905
MACH - Pan/utensilwashing machines - MLP140, MLP50, MLP56, MLP60, MLP60E
MARELS - Dishwasher hood type - OPT 100
MODULAR - Dishwasher - DW50, DW50DT, DW51, DW51DT, DWD51, DWD51DT, DWD59, DWD59DT, OPT910, OPT912, OPT960A
MODULAR - Dishwasher hood type - HT50, HT51, HT52DT, HT53DT, OPT1010, OPT1012, OPT1060A
